Technical Specifications
| Size Range NPS 1/2″-24″ / DN15-600mm | Main Material Carbon steel, Stainless Steel, Aluminum Bronze, Duplex steel etc.
(Other materials are available under request.) |
| Temperature Rating -196 ~ +500°C | Stem Material Stainless steel |
| Pressure Rating I.0Mpa ~ 26.0Mpa 150LB ~ 1500LB | Leakage Level Zero Leakage |
| Disc Material Carbon Steel, Stainless steel, Duplex steel etc. | Flange Drilling ASME B16.5, EN1092, GOST 33259, BS etc. |
| Seat Material Metal seat | Body Style Double Flanged,Butt Weld |
| Design Standard ASME B16.34, DIN 3356 | Test Standard API 598, EN12266-1, ISO 5208 |
| Face to Face ASME B16.10,EN558-1 | Operation Handwheel, Worm Gear, Electric, Pneumatic, etc. |
| Application Oil and Gas Pipeline, steam distribution systems, power generation, geothermal steam, pulp & paper liquor, refining, chemical processing, water & wastewater, nitric acid, acetic acid, oxidizing medium, urea |
| Other The carefully selected materials and contemporary design make our bellow globe valve highly recognized. If our bellow globe Valve cannot meet your choice, we can provide you with special made. |
Chief Features
The product has reasonable structure, reliable sealing, excellent performance and beautiful appearance;
The sealing surface is welded with Co-based cemented carbide, which is wear-resistant, corrosion resistant, good friction resistance and long service life;
The stem is quenched and tempered, and its surface is treated by nitriding treatment, thus it has good corrosion resistant and friction resistant.
It has double seal capability,thus it’s more reliable;
The stem show the position of lift,thus it is more visualized.
